Grade AISI 316L EN 1.4404 Stainless Steel Foil Precision Strip In Coil
Stainless 316L, 1.4404 is a modified type pf stainless grade 316, 1.4401 that eliminates
harmful carbide precipitation due to welding.
It is the most common grade which highlights the benefits of molybdenum (Mo).
Mo enhances the corrosion resistance of stainless steel even in relatively small amounts.
1% of Mo is worth about 3% of Cr in terms of corrosion resistance.
In environments where stainless 304 (1.4301) is found to be inadequate,
stainless 316L (1.4404) is the natural first grade to be considered.
Typical environments for stainless 316L (1.4404) is used are high chloride (saline, coastal),
heavy urban, acidic, high temperature solutions.
Like all austenitic stainless steels, 316L (1.4404) has good welding and forming characteristics.
Typical applications which demonstrate the improved corrosion resistance of 316L (1.4404) include:
Pharmaceutical plant, chemical processing, offshore oil and gas platform topside equipment, architectural
applications in urban and coastal conditions, food processing, water treatment, pressure vessels,
transport containers, swimming pool fittings and fixtures, marine structures, yacht fittings,
laboratory equipment, heat exchangers.
Grade
| AISI, UNS | EN, DIN | JIS |
| 316L, S31603 | 1.4404, X2CrNiMo17-12-2 | SUS316L |
Chemical composition ( weight % )
| Grade | C | Si | Mn | P | S | Cr | Ni | Mo | N |
| 316L | 0.03 max | 0.75 max | 2.00 max | 0.045 max | 0.030 max | 16.00~18.00 | 10.00~14.00 | 2.00~3.00 | 0.10 max |
Product forms
Precision stainless steel strip 316L, thickness 0.02~1.5mm
Stainless steel foil roll 316L, thickness 0.02~0.05mm
For Details, please Contact
Wuxi Guanglu Special Steel Co., Ltd. – your productivity partner for precision strip steel.
We are looking forward to your enquiries.
Please call +86 510-8181-2873
or send an email to export@guanglusteel.com
